STP16NF06FP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 60V 11A TO-220FP
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 1517
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Series STripFET? II
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 60V
Technology MOSFET (Metal Oxide)
Current Rating 11A
Base Part Number STP16N
Pin Count 3
Number of Elements 1
Power Dissipation-Max 25W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 25W
Case Connection ISOLATED
Turn On Delay Time 7 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 100m Ω @ 8A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 315pF @ 25V
Current - Continuous Drain (Id) @ 25°C 11A Tc
Gate Charge (Qg) (Max) @ Vgs 13nC @ 10V
Rise Time 18ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 6 ns
Turn-Off Delay Time 17 ns
Continuous Drain Current (ID) 8A
Threshold Voltage 4V
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage 60V
Pulsed Drain Current-Max (IDM) 44A
Dimensions
Height 16.4mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
