STP16N50M2
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 13A TO-220AB
PDF
/
Buying Options
Total Price: USD $7.19
Unit Price: USD $7.19435
≥1 USD $7.19435
≥10 USD $5.9033
≥100 USD $5.719
≥500 USD $5.5347
≥1000 USD $5.34945
Inventory: 1927
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series MDmesh? M2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STP16N
Power Dissipation-Max 110W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 280m Ω @ 6.5A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 710pF @ 100V
Current - Continuous Drain (Id) @ 25°C 13A Tc
Gate Charge (Qg) (Max) @ Vgs 19.5nC @ 10V
Drain to Source Voltage (Vdss) 500V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Continuous Drain Current (ID) 13A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
