STP14NM50N
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 12A TO-220
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.3848
≥1 USD $2.3848
≥10 USD $1.889184
≥100 USD $1.619376
≥500 USD $1.583894
Inventory: 911
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 15.75mm
Technical
Pulsed Drain Current-Max (IDM) 48A
Drain to Source Breakdown Voltage 500V
Gate to Source Voltage (Vgs) 25V
JEDEC-95 Code TO-220AB
Threshold Voltage 3V
Continuous Drain Current (ID) 12A
Turn-Off Delay Time 42 ns
Fall Time (Typ) 32 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 9 ns
Gate Charge (Qg) (Max) @ Vgs 27nC @ 10V
Current - Continuous Drain (Id) @ 25°C 12A Tc
Input Capacitance (Ciss) (Max) @ Vds 816pF @ 50V
Vgs(th) (Max) @ Id 4V @ 100μA
Rds On (Max) @ Id, Vgs 320m Ω @ 6A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 10.2 ns
Power Dissipation 90W
Operating Mode ENHANCEMENT MODE
Element Configuration Dual
Power Dissipation-Max 90W Tc
Number of Elements 1
Pin Count 3
Base Part Number STP14N
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish Matte Tin (Sn)
Resistance 320mOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series MDmesh? II
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
