STP100NF04
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 40V 120A 3-Pin(3+Tab) TO-220 Tube
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.4904
≥1 USD $2.4904
≥10 USD $1.976128
≥100 USD $1.693736
≥500 USD $1.505557
≥1000 USD $1.28913
≥3000 USD $1.213854
Inventory: 999
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 4.535924g
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Series Automotive, AEC-Q101, STripFET? II
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 4.6MOhm
Terminal Finish Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 40V
Technology MOSFET (Metal Oxide)
Current Rating 120A
Base Part Number STP100
Pin Count 3
Number of Elements 1
Power Dissipation-Max 300W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 300W
Turn On Delay Time 35 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 4.6m Ω @ 50A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 5100pF @ 25V
Current - Continuous Drain (Id) @ 25°C 120A Tc
Gate Charge (Qg) (Max) @ Vgs 150nC @ 10V
Rise Time 220ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 50 ns
Turn-Off Delay Time 80 ns
Continuous Drain Current (ID) 120A
Threshold Voltage 4V
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage 40V
Pulsed Drain Current-Max (IDM) 480A
Dimensions
Height 9.15mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
