STL80N4LLF3
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerVDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 40V 80A POWERFLAT6X5
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.3002
≥1 USD $0.3002
≥10 USD $0.247
≥100 USD $0.23845
≥500 USD $0.23085
≥1000 USD $0.22325
Inventory: 1621
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Nominal Vgs 1 V
Dual Supply Voltage 40V
Drain to Source Breakdown Voltage 40V
Drain-source On Resistance-Max 0.007Ohm
Drain Current-Max (Abs) (ID) 20A
Gate to Source Voltage (Vgs) 16V
Threshold Voltage 1V
Continuous Drain Current (ID) 10A
Turn-Off Delay Time 62 ns
Fall Time (Typ) 9 ns
Vgs (Max) ±16V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Rise Time 25ns
Gate Charge (Qg) (Max) @ Vgs 28nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 80A Tc
Input Capacitance (Ciss) (Max) @ Vds 2530pF @ 25V
Vgs(th) (Max) @ Id 1V @ 250μA
Rds On (Max) @ Id, Vgs 5m Ω @ 10A, 10V
FET Type N-Channel
Power Dissipation 80W
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 80W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 8
Base Part Number STL80
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) 225
Terminal Form NO LEAD
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish MATTE TIN
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series STripFET?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 8
Package / Case 8-PowerVDFN
Mounting Type Surface Mount
Mount Surface Mount
