STL18NM60N
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerVDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 6A POWERFLAT
PDF
/
Buying Options
Total Price: USD $3.2
Unit Price: USD $3.2032
≥1 USD $3.2032
≥10 USD $2.68928
≥100 USD $2.1758
≥500 USD $1.934029
≥1000 USD $1.65601
Inventory: 1262
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 8mm
Length 8mm
Height 950μm
Technical
Pulsed Drain Current-Max (IDM) 8.4A
Drain to Source Breakdown Voltage 600V
Drain Current-Max (Abs) (ID) 2.1A
Gate to Source Voltage (Vgs) 25V
Threshold Voltage 3V
Continuous Drain Current (ID) 12A
Turn-Off Delay Time 50 ns
Fall Time (Typ) 40 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 22 ns
Gate Charge (Qg) (Max) @ Vgs 35nC @ 10V
Current - Continuous Drain (Id) @ 25°C 2.1A Ta 12A Tc
Input Capacitance (Ciss) (Max) @ Vds 1000pF @ 50V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 310m Ω @ 6A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 20 ns
Case Connection DRAIN
Power Dissipation 110W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 3W Ta 110W Tc
Number of Elements 1
Pin Count 5
Base Part Number STL18
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Resistance 310mOhm
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series MDmesh? II
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 5
Package / Case 8-PowerVDFN
Mounting Type Surface Mount
Mount Surface Mount
