STI33N60M2
RoHS
RoHS compliant
RoHS compliantPackage TO-262-3 Long Leads, I2Pak, TO-262AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 26A I2PAK
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 1407
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Through Hole
Weight 2.084002g
Package / Case TO-262-3 Long Leads, I2Pak, TO-262AA
Mounting Type Through Hole
Compliance
RoHS Status ROHS3 Compliant
Technical
Gate to Source Voltage (Vgs) 25V
Continuous Drain Current (ID) 26A
Turn-Off Delay Time 109 ns
Fall Time (Typ) 9 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 600V
Rise Time 9.6ns
Gate Charge (Qg) (Max) @ Vgs 45.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 26A Tc
Input Capacitance (Ciss) (Max) @ Vds 1781pF @ 100V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 125m Ω @ 13A, 10V
FET Type N-Channel
Turn On Delay Time 16 ns
Element Configuration Single
Power Dissipation-Max 190W Tc
Number of Channels 1
Base Part Number STI33N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Resistance 108mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? II Plus
Packaging Tube
Operating Temperature -55°C~150°C TJ
