STH290N4F6-2AG
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 40V 180A H2PAK-2
PDF
/
Inventory: 7586
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, STripFET?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
DS Breakdown Voltage-Min 40V
Pulsed Drain Current-Max (IDM) 720A
Drain-source On Resistance-Max 0.0017Ohm
Continuous Drain Current (ID) 180A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 40V
Gate Charge (Qg) (Max) @ Vgs 115nC @ 10V
Current - Continuous Drain (Id) @ 25°C 180A Tc
Input Capacitance (Ciss) (Max) @ Vds 7380pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 1.7m Ω @ 45A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 300W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number STH290
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Number of Terminations 2
Compliance
RoHS Status ROHS3 Compliant
