STFW12N120K5
RoHS
RoHS compliant
RoHS compliantPackage ISOWATT218FX
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-channel 1200 V, 0.58 Ohm typ., 12 A Zener-protected MDmesh K5 Power MOSFET in TO-3PF packge
PDF
/
Buying Options
Total Price: USD $10.55
Unit Price: USD $10.548546
≥1 USD $10.548546
≥10 USD $9.951451
≥100 USD $9.388163
≥500 USD $8.856763
≥1000 USD $8.355434
Inventory: 1280
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
DS Breakdown Voltage-Min 1200V
Pulsed Drain Current-Max (IDM) 48A
Drain-source On Resistance-Max 0.69Ohm
Drain Current-Max (Abs) (ID) 12A
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 1200V
Gate Charge (Qg) (Max) @ Vgs 44.2nC @ 10V
Current - Continuous Drain (Id) @ 25°C 12A Tc
Input Capacitance (Ciss) (Max) @ Vds 1370pF @ 100V
Vgs(th) (Max) @ Id 5V @ 100μA
Rds On (Max) @ Id, Vgs 690m Ω @ 6A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 63W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number STFW
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Powers
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? K5
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case ISOWATT218FX
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 12 Weeks
