STFI20NM65N
RoHS
RoHS compliant
RoHS compliantPackage TO-262-3 Full Pack, I2Pak
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 650V 15A I2PAK-FP
PDF
/
Buying Options
Total Price: USD $4.22
Unit Price: USD $4.2152
≥1 USD $4.2152
≥10 USD $3.341008
≥100 USD $2.863696
≥500 USD $2.545523
≥1000 USD $2.179602
Inventory: 1171
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Drain to Source Breakdown Voltage 710V
Gate to Source Voltage (Vgs) 25V
Continuous Drain Current (ID) 15A
Turn-Off Delay Time 75 ns
Fall Time (Typ) 21 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 650V
Rise Time 13.5ns
Gate Charge (Qg) (Max) @ Vgs 44nC @ 10V
Current - Continuous Drain (Id) @ 25°C 15A Tc
Input Capacitance (Ciss) (Max) @ Vds 1280pF @ 50V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 270m Ω @ 7.5A, 10V
FET Type N-Channel
Turn On Delay Time 15 ns
Element Configuration Single
Power Dissipation-Max 30W Tc
Number of Channels 1
Base Part Number STFI20N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Resistance 250mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series MDmesh? II
Packaging Tube
Operating Temperature 150°C TJ
Physical
Weight 2.240009g
Package / Case TO-262-3 Full Pack, I2Pak
Mounting Type Through Hole
Mount Through Hole
