STF40N20
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 200V 40A TO-220FP
PDF
/
Inventory: 9456
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series STripFET?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 200V
Technology MOSFET (Metal Oxide)
Current Rating 40A
Base Part Number STF40N
Pin Count 3
Number of Elements 1
Power Dissipation-Max 40W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 40W
Case Connection ISOLATED
Turn On Delay Time 20 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 45m Ω @ 20A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2500pF @ 25V
Current - Continuous Drain (Id) @ 25°C 40A Tc
Gate Charge (Qg) (Max) @ Vgs 75nC @ 10V
Rise Time 44ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 22 ns
Turn-Off Delay Time 74 ns
Continuous Drain Current (ID) 40A
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 20V
Drain-source On Resistance-Max 0.045Ohm
Drain to Source Breakdown Voltage 200V
Pulsed Drain Current-Max (IDM) 160A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
