STF38N65M5
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 650V 30A TO-220FP
PDF
/
Buying Options
Total Price: USD $3.53
Unit Price: USD $3.5288
≥1 USD $3.5288
≥10 USD $2.79752
≥100 USD $2.397824
≥500 USD $2.345306
Inventory: 1135
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Series MDmesh? V
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 95mOhm
Terminal Finish MATTE TIN
Additional Feature ULTRA LOW RESISTANCE
Subcategory FET General Purpose Powers
Technology MOSFET (Metal Oxide)
Base Part Number STF38N
Number of Elements 1
Power Dissipation-Max 35W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 35W
Case Connection ISOLATED
Turn On Delay Time 66 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 95m Ω @ 15A, 10V
Vgs(th) (Max) @ Id 5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 3000pF @ 100V
Current - Continuous Drain (Id) @ 25°C 30A Tc
Gate Charge (Qg) (Max) @ Vgs 71nC @ 10V
Rise Time 9 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Fall Time (Typ) 9 ns
Turn-Off Delay Time 66 ns
Continuous Drain Current (ID) 30A
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 25V
Drain to Source Breakdown Voltage 650V
Avalanche Energy Rating (Eas) 660 mJ
Dimensions
Height 16.4mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
