STF28N65M2
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 650V 20A TO220FP
PDF
/
Buying Options
Total Price: USD $2.62
Unit Price: USD $2.6224
≥1 USD $2.6224
≥10 USD $2.07768
≥100 USD $1.780944
≥500 USD $1.583067
≥1000 USD $1.35549
≥3000 USD $1.276343
Inventory: 2078
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.6mm
Length 10.4mm
Height 16.4mm
Technical
Avalanche Energy Rating (Eas) 760 mJ
DS Breakdown Voltage-Min 650V
Pulsed Drain Current-Max (IDM) 80A
Drain-source On Resistance-Max 0.18Ohm
Gate to Source Voltage (Vgs) 25V
JEDEC-95 Code TO-220AB
Continuous Drain Current (ID) 20A
Turn-Off Delay Time 59 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 650V
Gate Charge (Qg) (Max) @ Vgs 35nC @ 10V
Current - Continuous Drain (Id) @ 25°C 20A Tc
Input Capacitance (Ciss) (Max) @ Vds 1440pF @ 100V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 180m Ω @ 10A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 13.4 ns
Case Connection ISOLATED
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 30W Tc
Number of Elements 1
Base Part Number STF28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? M2
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 16 Weeks
Alternative Model
