STF25NM50N
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 22A TO220FP
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.61975
≥1 USD $1.61975
≥10 USD $1.32905
≥100 USD $1.28725
≥500 USD $1.24545
≥1000 USD $1.2046
Inventory: 1558
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Series MDmesh? II
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 140mOhm
Terminal Finish Matte Tin (Sn) - annealed
Subcategory FET General Purpose Power
Voltage - Rated DC 550V
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 22A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STF25
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 40W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 40W
Case Connection ISOLATED
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 140m Ω @ 11A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2565pF @ 25V
Current - Continuous Drain (Id) @ 25°C 22A Tc
Gate Charge (Qg) (Max) @ Vgs 84nC @ 10V
Rise Time 23ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Fall Time (Typ) 22 ns
Turn-Off Delay Time 75 ns
Continuous Drain Current (ID) 22A
Threshold Voltage 3V
JEDEC-95 Code TO-220AB
Gate to Source Voltage (Vgs) 25V
Drain to Source Breakdown Voltage 500V
Pulsed Drain Current-Max (IDM) 88A
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
