STF25N10F7
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 100V 25A TO-220FP
PDF
/
Buying Options
Total Price: USD $6.91
Unit Price: USD $6.91315
≥1 USD $6.91315
≥10 USD $5.67245
≥100 USD $5.4948
≥500 USD $5.3181
≥1000 USD $5.14045
Inventory: 1338
Minimum: 1
-
+
Technical Details
Technical
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 4.6 ns
Turn-Off Delay Time 14.8 ns
Continuous Drain Current (ID) 19A
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage 100V
Rise Time 14ns
Gate Charge (Qg) (Max) @ Vgs 14nC @ 10V
Current - Continuous Drain (Id) @ 25°C 19A Tc
Input Capacitance (Ciss) (Max) @ Vds 920pF @ 50V
Vgs(th) (Max) @ Id 4.5V @ 250μA
Rds On (Max) @ Id, Vgs 35m Ω @ 12.5A, 10V
FET Type N-Channel
Turn On Delay Time 9.8 ns
Element Configuration Single
Power Dissipation-Max 25W Tc
Number of Channels 1
Base Part Number STF25
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DeepGATE?, STripFET? VII
Packaging Tube
Operating Temperature -55°C~175°C TJ
Dimensions
Height 16.4mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 329.988449mg
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 37 Weeks
