STF140N6F7
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
N-CHANNEL 60 V, 0.0031 OHM TYP.,
PDF
/
Buying Options
Total Price: USD $1.76
Unit Price: USD $1.76
≥1 USD $1.76
≥10 USD $1.411344
≥100 USD $1.161248
≥500 USD $0.982573
≥1000 USD $0.833694
≥3000 USD $0.792009
Inventory: 963
Minimum: 1
-
+
Technical Details
Technical
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 55nC @ 10V
Current - Continuous Drain (Id) @ 25°C 70A Tc
Input Capacitance (Ciss) (Max) @ Vds 3100pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 3.5m Ω @ 35A, 10V
FET Type N-Channel
Power Dissipation-Max 33W Tc
Base Part Number STF14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series STripFET?
Packaging Tube
Operating Temperature 175°C TJ
Compliance
RoHS Status ROHS3 Compliant
Physical
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 22 Weeks
