STF13N95K3
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-Ch 950V 0.68 Ohm 10A SuperMESH3
PDF
/
Buying Options
Total Price: USD $5.38
Unit Price: USD $5.3768
≥1 USD $5.3768
≥10 USD $4.291056
≥100 USD $3.839352
≥500 USD $3.387666
≥1000 USD $3.048892
≥3000 USD $2.856929
Inventory: 1041
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Avalanche Energy Rating (Eas) 400 mJ
Pulsed Drain Current-Max (IDM) 40A
Drain to Source Breakdown Voltage 950V
Gate to Source Voltage (Vgs) 30V
JEDEC-95 Code TO-220AB
Continuous Drain Current (ID) 10A
Turn-Off Delay Time 50 ns
Fall Time (Typ) 21 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 16 ns
Gate Charge (Qg) (Max) @ Vgs 51nC @ 10V
Current - Continuous Drain (Id) @ 25°C 10A Tc
Input Capacitance (Ciss) (Max) @ Vds 1620pF @ 100V
Vgs(th) (Max) @ Id 5V @ 100μA
Rds On (Max) @ Id, Vgs 850m Ω @ 5A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 18 ns
Case Connection ISOLATED
Power Dissipation 40W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 40W Tc
Number of Elements 1
Pin Count 3
Base Part Number STF13
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Additional Feature ULTRA-LOW RESISTANCE
Resistance 850MOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SuperMESH3?
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
