STF11N65M5
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N CH 650V 9A TO-220FP
PDF
/
Buying Options
Total Price: USD $1.89
Unit Price: USD $1.892
≥1 USD $1.892
≥10 USD $1.516592
≥100 USD $1.24784
≥500 USD $1.055894
≥1000 USD $0.89591
≥3000 USD $0.851118
Inventory: 38
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 16.4mm
Technical
Drain to Source Breakdown Voltage 650V
Drain-source On Resistance-Max 0.48Ohm
Drain Current-Max (Abs) (ID) 9A
Gate to Source Voltage (Vgs) 25V
JEDEC-95 Code TO-220AB
Continuous Drain Current (ID) 9A
Turn-Off Delay Time 23 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Gate Charge (Qg) (Max) @ Vgs 17nC @ 10V
Current - Continuous Drain (Id) @ 25°C 9A Tc
Input Capacitance (Ciss) (Max) @ Vds 644pF @ 100V
Vgs(th) (Max) @ Id 5V @ 250μA
Rds On (Max) @ Id, Vgs 480m Ω @ 4.5A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 23 ns
Power Dissipation 85W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 25W Tc
Number of Elements 1
Base Part Number STF11
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? V
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 17 Weeks
