STD9N80K5
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CHANNEL 800V 7A DPAK
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 7273
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series MDmesh? K5
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STD9N
Power Dissipation-Max 110W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 900m Ω @ 3.5A, 10V
Vgs(th) (Max) @ Id 5V @ 100μA
Input Capacitance (Ciss) (Max) @ Vds 340pF @ 100V
Current - Continuous Drain (Id) @ 25°C 7A Tc
Gate Charge (Qg) (Max) @ Vgs 12nC @ 10V
Drain to Source Voltage (Vdss) 800V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Compliance
RoHS Status ROHS3 Compliant
