STD9N40M2
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 400V 6A DPAK
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.71984
≥100 USD $0.559944
≥500 USD $0.474619
≥1000 USD $0.386628
Inventory: 1172
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Continuous Drain Current (ID) 6A
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 400V
Gate Charge (Qg) (Max) @ Vgs 8.8nC @ 10V
Current - Continuous Drain (Id) @ 25°C 6A Tc
Input Capacitance (Ciss) (Max) @ Vds 270pF @ 100V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 800m Ω @ 3A, 10V
FET Type N-Channel
Power Dissipation-Max 60W Tc
Base Part Number STD9N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? II Plus
Packaging Cut Tape (CT)
Operating Temperature -55°C~150°C TJ
Physical
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 16 Weeks
