STD95N04
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET STripFET MOSFET
PDF
/
Inventory: 6789
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Series STripFET?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory FET General Purpose Power
Voltage - Rated DC 40V
Technology MOSFET (Metal Oxide)
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Reach Compliance Code not_compliant
Current Rating 80A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STD95
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 110W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 110W
Case Connection DRAIN
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 6.5m Ω @ 40A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2200pF @ 25V
Current - Continuous Drain (Id) @ 25°C 80A Tc
Gate Charge (Qg) (Max) @ Vgs 54nC @ 10V
Rise Time 50ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 15 ns
Turn-Off Delay Time 40 ns
Continuous Drain Current (ID) 80A
JEDEC-95 Code TO-252AA
Gate to Source Voltage (Vgs) 20V
Drain-source On Resistance-Max 0.0065Ohm
Drain to Source Breakdown Voltage 40V
Pulsed Drain Current-Max (IDM) 320A
Avalanche Energy Rating (Eas) 400 mJ
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
