STD90N02L
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 25V 60A DPAK
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 2268
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Pulsed Drain Current-Max (IDM) 240A
Drain to Source Breakdown Voltage 25V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 60A
Turn-Off Delay Time 18 ns
Fall Time (Typ) 8 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 5V 10V
Rise Time 110ns
Gate Charge (Qg) (Max) @ Vgs 22nC @ 5V
Current - Continuous Drain (Id) @ 25°C 60A Tc
Input Capacitance (Ciss) (Max) @ Vds 2050pF @ 16V
Vgs(th) (Max) @ Id 1.8V @ 250μA
Rds On (Max) @ Id, Vgs 6m Ω @ 30A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Power Dissipation 70W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 70W Tc
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STD90
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 60A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Voltage - Rated DC 24V
Subcategory FET General Purpose Power
Additional Feature LOW THRESHOLD
Terminal Finish MATTE TIN
Resistance 6mOhm
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series STripFET? III
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
