STD7NM80
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET, N CH, 800V, 6.5A, DPAK
PDF
/
Buying Options
Total Price: USD $3.35
Unit Price: USD $3.3528
≥1 USD $3.3528
≥10 USD $2.81424
≥100 USD $2.27656
≥500 USD $2.023613
≥1000 USD $1.732729
Inventory: 4355
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.2mm
Length 6.6mm
Height 2.4mm
Technical
Nominal Vgs 4 V
Avalanche Energy Rating (Eas) 240 mJ
Dual Supply Voltage 800V
Pulsed Drain Current-Max (IDM) 26A
Drain to Source Breakdown Voltage 800V
Gate to Source Voltage (Vgs) 30V
Threshold Voltage 4V
Continuous Drain Current (ID) 6.5A
Turn-Off Delay Time 35 ns
Fall Time (Typ) 10 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 8 ns
Gate Charge (Qg) (Max) @ Vgs 18nC @ 10V
Current - Continuous Drain (Id) @ 25°C 6.5A Tc
Input Capacitance (Ciss) (Max) @ Vds 620pF @ 25V
Vgs(th) (Max) @ Id 5V @ 250μA
Rds On (Max) @ Id, Vgs 1.05 Ω @ 3.25A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 20 ns
Case Connection ISOLATED
Power Dissipation 90W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 90W Tc
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STD7
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish Matte Tin (Sn) - annealed
Resistance 1.05Ohm
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series MDmesh?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 16 Weeks
