STD70N6F3
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 60V 70A DPAK
PDF
/
Buying Options
Total Price: USD $1.74
Unit Price: USD $1.7424
≥1 USD $1.7424
≥10 USD $1.44848
≥100 USD $1.152536
≥500 USD $0.975234
≥1000 USD $0.827473
Inventory: 1094
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Pulsed Drain Current-Max (IDM) 280A
Drain to Source Breakdown Voltage 60V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 70A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Gate Charge (Qg) (Max) @ Vgs 35nC @ 10V
Current - Continuous Drain (Id) @ 25°C 70A Tc
Input Capacitance (Ciss) (Max) @ Vds 2200pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 10.5m Ω @ 35A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Power Dissipation 110W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 110W Tc
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STD70N
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish Matte Tin (Sn) - annealed
Resistance 10.5MOhm
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series STripFET? III
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
