STD60NF55LAT4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 55V 60A Automotive 3-Pin(2+Tab) DPAK T/R
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
≥10 USD $1.22232
≥100 USD $0.972664
≥500 USD $0.823046
≥1000 USD $0.69835
Inventory: 1465
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Avalanche Energy Rating (Eas) 400 mJ
DS Breakdown Voltage-Min 55V
Pulsed Drain Current-Max (IDM) 240A
Gate to Source Voltage (Vgs) 15V
Continuous Drain Current (ID) 60A
Turn-Off Delay Time 80 ns
Fall Time (Typ) 35 ns
Vgs (Max) ±15V
Drive Voltage (Max Rds On,Min Rds On) 5V 10V
Drain to Source Voltage (Vdss) 55V
Rise Time 180 ns
Gate Charge (Qg) (Max) @ Vgs 40nC @ 5V
Current - Continuous Drain (Id) @ 25°C 60A Tc
Input Capacitance (Ciss) (Max) @ Vds 1950pF @ 25V
Vgs(th) (Max) @ Id 2V @ 250μA
Rds On (Max) @ Id, Vgs 15m Ω @ 30A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 30 ns
Power Dissipation 110W
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 110W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STD60N
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Additional Feature LOW THRESHOLD
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SuperFET? II
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
