STD45P4LLF6AG
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 40V 50A DPAK
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4344
≥1 USD $1.4344
≥10 USD $1.19416
≥100 USD $0.950312
≥500 USD $0.804126
≥1000 USD $0.682282
Inventory: 3900
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Technical
Operating Temperature -55°C~150°C TJ
Packaging Cut Tape (CT)
Series Automotive, AEC-Q101, STripFET? F6
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STD45
Power Dissipation-Max 58W Tc
FET Type P-Channel
Rds On (Max) @ Id, Vgs 15m Ω @ 25A, 10V
Vgs(th) (Max) @ Id 2.5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 3525pF @ 25V
Current - Continuous Drain (Id) @ 25°C 50A Tc
Gate Charge (Qg) (Max) @ Vgs 65.5nC @ 10V
Drain to Source Voltage (Vdss) 40V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Vgs (Max) ±18V
Continuous Drain Current (ID) 50A
Compliance
RoHS Status ROHS3 Compliant
