Drain to Source Breakdown Voltage 40V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 44A
Turn-Off Delay Time 30 ns
Drive Voltage (Max Rds On,Min Rds On) 5V 10V
Gate Charge (Qg) (Max) @ Vgs 22nC @ 10V
Current - Continuous Drain (Id) @ 25°C 44A Tc
Input Capacitance (Ciss) (Max) @ Vds 1190pF @ 25V
Vgs(th) (Max) @ Id 2.5V @ 250μA
Rds On (Max) @ Id, Vgs 12.5m Ω @ 20A, 10V
Transistor Application SWITCHING
Turn On Delay Time 8.5 ns
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 50W Tc
Peak Reflow Temperature (Cel) 260
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish Matte Tin (Sn) - annealed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Series DeepGATE?, STripFET? VI
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
