STD3N80K5
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 800V 2.5A 3-Pin(2+Tab) DPAK T/R
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.1704
≥1 USD $1.1704
≥10 USD $0.95832
≥100 USD $0.745272
≥500 USD $0.631717
≥1000 USD $0.514598
Inventory: 4984
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.2mm
Length 6.6mm
Height 2.4mm
Technical
Avalanche Energy Rating (Eas) 65 mJ
Drain to Source Breakdown Voltage 800V
Gate to Source Voltage (Vgs) 30V
Continuous Drain Current (ID) 2.5A
Turn-Off Delay Time 20.5 ns
Fall Time (Typ) 25 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 7.5 ns
Gate Charge (Qg) (Max) @ Vgs 9.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 2.5A Tc
Input Capacitance (Ciss) (Max) @ Vds 130pF @ 100V
Vgs(th) (Max) @ Id 5V @ 100μA
Rds On (Max) @ Id, Vgs 3.5 Ω @ 1A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 8.5 ns
Case Connection DRAIN
Power Dissipation 110W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 60W Tc
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number STD3N
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SuperMESH5?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 3.949996g
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
