STD30NF04LT
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 40V 30A DPAK
PDF
/
Inventory: 3192
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Series STripFET? II
Part Status Active
Continuous Drain Current (ID) 30A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 5V 10V
Drain to Source Voltage (Vdss) 40V
Gate Charge (Qg) (Max) @ Vgs 25nC @ 10V
Current - Continuous Drain (Id) @ 25°C 30A Tc
Input Capacitance (Ciss) (Max) @ Vds 720pF @ 25V
Vgs(th) (Max) @ Id 2.5V @ 250μA
Rds On (Max) @ Id, Vgs 30m Ω @ 15A, 10V
FET Type N-Channel
Power Dissipation-Max 50W Tc
Configuration Single
Base Part Number STD30N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Powers
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Compliance
RoHS Status ROHS3 Compliant
