STD2N95K5
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 950V 2A DPAK
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.3288
≥1 USD $1.3288
≥10 USD $1.0868
≥100 USD $0.845504
≥500 USD $0.716672
≥1000 USD $0.58381
Inventory: 1541
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.2mm
Length 6.6mm
Height 2.4mm
Technical
Avalanche Energy Rating (Eas) 50 mJ
Pulsed Drain Current-Max (IDM) 8A
Drain to Source Breakdown Voltage 950V
Drain-source On Resistance-Max 5Ohm
Drain Current-Max (Abs) (ID) 2A
Gate to Source Voltage (Vgs) 30V
Continuous Drain Current (ID) 2A
Turn-Off Delay Time 20.5 ns
Fall Time (Typ) 32.5 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 13.5 ns
Gate Charge (Qg) (Max) @ Vgs 10nC @ 10V
Current - Continuous Drain (Id) @ 25°C 2A Tc
Input Capacitance (Ciss) (Max) @ Vds 105pF @ 100V
Vgs(th) (Max) @ Id 5V @ 100μA
Rds On (Max) @ Id, Vgs 5 Ω @ 1A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 8.5 ns
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 45W Tc
Number of Channels 1
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number STD2N95
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SuperMESH5?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 3.949996g
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 17 Weeks
