STD13NM60ND
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
N-Channel 600 V 0.38 Ohm SMT FDmesh II Power Mosfet - DPAK
PDF
/
Buying Options
Total Price: USD $3.68
Unit Price: USD $3.6784
≥1 USD $3.6784
≥10 USD $3.08704
≥100 USD $2.497176
≥500 USD $2.21973
≥1000 USD $1.900642
Inventory: 1729
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.2mm
Length 6.6mm
Height 2.4mm
Technical
Pulsed Drain Current-Max (IDM) 44A
Drain to Source Breakdown Voltage 650V
Gate to Source Voltage (Vgs) 25V
Continuous Drain Current (ID) 11A
Turn-Off Delay Time 9.6 ns
Fall Time (Typ) 15.4 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 600V
Rise Time 10 ns
Gate Charge (Qg) (Max) @ Vgs 24.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 11A Tc
Input Capacitance (Ciss) (Max) @ Vds 845pF @ 50V
Vgs(th) (Max) @ Id 5V @ 250μA
Rds On (Max) @ Id, Vgs 380m Ω @ 5.5A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 46.5 ns
Case Connection DRAIN
Power Dissipation 109W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 109W Tc
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number STD13
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Resistance 380mOhm
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series FDmesh? II
Packaging Cut Tape (CT)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
