STB13N60M2
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 11A D2PAK
PDF
/
Buying Options
Total Price: USD $1.98
Unit Price: USD $1.98
≥1 USD $1.98
≥10 USD $1.64384
≥100 USD $1.308736
≥500 USD $1.107374
Inventory: 6180
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Cut Tape (CT)
Series MDmesh? II Plus
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Resistance 380mOhm
Technology MOSFET (Metal Oxide)
Terminal Form GULL WING
Base Part Number STB13N
JESD-30 Code R-PSSO-G2
Number of Elements 1
Power Dissipation-Max 110W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 110W
Case Connection DRAIN
Turn On Delay Time 11 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 380m Ω @ 5.5A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 580pF @ 100V
Current - Continuous Drain (Id) @ 25°C 11A Tc
Gate Charge (Qg) (Max) @ Vgs 17nC @ 10V
Rise Time 10 ns
Drain to Source Voltage (Vdss) 600V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Fall Time (Typ) 9.5 ns
Turn-Off Delay Time 41 ns
Continuous Drain Current (ID) 11A
Gate to Source Voltage (Vgs) 25V
Drain to Source Breakdown Voltage 650V
Pulsed Drain Current-Max (IDM) 44A
Avalanche Energy Rating (Eas) 125 mJ
Dimensions
Height 4.6mm
Length 10.4mm
Width 9.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
