NTD85N02RT4G
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
N-CHANNEL POWER MOSFET
PDF
/
Buying Options
Total Price: USD $10.24
Unit Price: USD $10.2372
≥1 USD $10.2372
≥10 USD $8.3999
≥100 USD $8.1377
≥500 USD $7.8755
≥1000 USD $7.61235
Inventory: 8410
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Avalanche Energy Rating (Eas) 85 mJ
DS Breakdown Voltage-Min 24V
Pulsed Drain Current-Max (IDM) 192A
Drain-source On Resistance-Max 0.0052Ohm
Drain Current-Max (Abs) (ID) 85A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 24V
Gate Charge (Qg) (Max) @ Vgs 17.7nC @ 5V
Current - Continuous Drain (Id) @ 25°C 12A Ta 85A Tc
Input Capacitance (Ciss) (Max) @ Vds 2.05pF @ 20V
Vgs(th) (Max) @ Id 2V @ 250μA
Rds On (Max) @ Id, Vgs 5.2m Ω @ 20A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 1.25W Ta 78.1W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Terminal Finish MATTE TIN
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
