MTB30P06VT4
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
P-CHANNEL POWER MOSFET
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 2350
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Avalanche Energy Rating (Eas) 450 mJ
DS Breakdown Voltage-Min 60V
Pulsed Drain Current-Max (IDM) 105A
Drain-source On Resistance-Max 0.08Ohm
Drain Current-Max (Abs) (ID) 30A
Vgs (Max) ±15V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 80nC @ 10V
Current - Continuous Drain (Id) @ 25°C 30A Tc
Input Capacitance (Ciss) (Max) @ Vds 2.19pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 80m Ω @ 15A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 3W Ta 125W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Additional Feature AVALANCHE RATED
Terminal Finish TIN LEAD
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
