IRFS540A
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
N-CHANNEL POWER MOSFET
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.6248
≥1 USD $0.6248
Inventory: 89242
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Avalanche Energy Rating (Eas) 385 mJ
DS Breakdown Voltage-Min 100V
Pulsed Drain Current-Max (IDM) 110A
Drain-source On Resistance-Max 0.052Ohm
Drain Current-Max (Abs) (ID) 17A
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 100V
Gate Charge (Qg) (Max) @ Vgs 78nC @ 10V
Current - Continuous Drain (Id) @ 25°C 17A Tc
Input Capacitance (Ciss) (Max) @ Vds 1.71pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 52m Ω @ 8.5A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection ISOLATED
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 39W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Terminal Finish MATTE TIN
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
