2SJ650
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
P-CHANNEL SILICON MOSFET
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
Inventory: 516532
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
DS Breakdown Voltage-Min 60V
Pulsed Drain Current-Max (IDM) 48A
Drain-source On Resistance-Max 0.205Ohm
Drain Current-Max (Abs) (ID) 12A
JEDEC-95 Code TO-220AB
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 21nC @ 10V
Current - Continuous Drain (Id) @ 25°C 12A Ta
Input Capacitance (Ciss) (Max) @ Vds 1020pF @ 20V
Rds On (Max) @ Id, Vgs 135m Ω @ 6A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Case Connection ISOLATED
Operating Mode DEPLETION MODE
Power Dissipation-Max 2W Ta 20W Tc
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSFM-T3
Pin Count 3
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
