NVMFS5113PLWFT1G
RoHS
/
Package 8-PowerTDFN, 5 Leads
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
NFET SO8FL 60V 69A 16MOHM
PDF
/
Buying Options
Total Price: USD $2.61
Unit Price: USD $2.6136
≥1 USD $2.6136
≥10 USD $2.16744
≥100 USD $1.7248
≥500 USD $1.45948
Inventory: 1119
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Avalanche Energy Rating (Eas) 315 mJ
DS Breakdown Voltage-Min 60V
Pulsed Drain Current-Max (IDM) 415A
Drain-source On Resistance-Max 0.014Ohm
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 83nC @ 10V
Current - Continuous Drain (Id) @ 25°C 10A Ta 64A Tc
Input Capacitance (Ciss) (Max) @ Vds 4400pF @ 25V
Vgs(th) (Max) @ Id 2.5V @ 250μA
Rds On (Max) @ Id, Vgs 14m Ω @ 17A, 10V
FET Type P-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 3.8W Ta 150W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-PDSO-F5
Terminal Form FLAT
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Terminal Finish Tin (Sn)
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q101
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case 8-PowerTDFN, 5 Leads
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 17 Weeks
