NVMFS024N06CT1G

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 8-PowerTDFN, 5 Leads
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description T6 60V SG HIGHER RDS-ON P
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.771985
≥1 USD $0.771985
≥10 USD $0.639382
≥30 USD $0.572424
≥100 USD $0.506779
≥500 USD $0.467392
≥1500 USD $0.446386
Inventory: 1113
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 14 Weeks

Physical

Mounting Type Surface Mount
Package / Case 8-PowerTDFN, 5 Leads

Technical

Operating Temperature -55°C~175°C TJ
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Power Dissipation-Max 3.4W Ta 28W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 22m Ω @ 3A, 10V
Vgs(th) (Max) @ Id 4V @ 20μA
Input Capacitance (Ciss) (Max) @ Vds 333pF @ 30V
Current - Continuous Drain (Id) @ 25°C 8A Ta 25A Tc
Gate Charge (Qg) (Max) @ Vgs 5.7nC @ 10V
Drain to Source Voltage (Vdss) 60V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V

Compliance

RoHS Status ROHS3 Compliant
