NTMFS5C628NLT1G
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerTDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 60V SO8FL
PDF
/
Buying Options
Total Price: USD $0.82
Unit Price: USD $0.82061
≥1 USD $0.82061
≥10 USD $0.77416
≥100 USD $0.73034
≥500 USD $0.689
≥1000 USD $0.65
≥3000 USD $0.61321
Inventory: 7009
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 1.1mm
Technical
Max Junction Temperature (Tj) 175°C
Drain to Source Breakdown Voltage 60V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 28A
Turn-Off Delay Time 28 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Gate Charge (Qg) (Max) @ Vgs 52nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds 3600pF @ 25V
Vgs(th) (Max) @ Id 2V @ 135μA
Rds On (Max) @ Id, Vgs 2.4m Ω @ 50A, 10V
FET Type N-Channel
Turn On Delay Time 15 ns
Power Dissipation 3.7W
Power Dissipation-Max 3.7W Ta 110W Tc
Number of Channels 1
Reach Compliance Code not_compliant
Technology MOSFET (Metal Oxide)
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Number of Pins 8
Package / Case 8-PowerTDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 11 hours ago)
Factory Lead Time 16 Weeks
