NTLUS020N03CTAG
RoHS
RoHS compliant
RoHS compliantPackage 6-PowerUFDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
T6 30V NCH 1.6X1.6 UDFN
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.44176
≥100 USD $0.305536
≥500 USD $0.255323
≥1000 USD $0.21729
Inventory: 1155
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 30V
Gate Charge (Qg) (Max) @ Vgs 11nC @ 10V
Current - Continuous Drain (Id) @ 25°C 5.3A Ta
Input Capacitance (Ciss) (Max) @ Vds 620pF @ 15V
Vgs(th) (Max) @ Id 2.2V @ 250μA
Rds On (Max) @ Id, Vgs 13m Ω @ 8A, 10V
FET Type N-Channel
Power Dissipation-Max 650mW Ta
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series μCool?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Package / Case 6-PowerUFDFN
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
