NDTL01N60ZT1G

ON Semiconductor
RoHS
/
Package TO-261-4, TO-261AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description MOSFET N-CH 600V 0.25A SOT223-4
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
Inventory: 1183
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA

Technical

Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2014
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 15Ohm
Terminal Finish Tin (Sn)
Technology MOSFET (Metal Oxide)
Power Dissipation-Max 2W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 15 Ω @ 400mA, 10V
Vgs(th) (Max) @ Id 4.5V @ 50μA
Input Capacitance (Ciss) (Max) @ Vds 92pF @ 25V
Current - Continuous Drain (Id) @ 25°C 250mA Tc
Gate Charge (Qg) (Max) @ Vgs 4.9nC @ 10V
Drain to Source Voltage (Vdss) 600V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Continuous Drain Current (ID) 250mA

Compliance

RoHS Status RoHS Compliant
