MTD2955VT4
RoHS
/
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 60V 12A DPAK
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.12445
≥1 USD $0.12445
≥10 USD $0.1026
≥100 USD $0.09975
≥500 USD $0.09595
≥1000 USD $0.0931
≥10000 USD $0.0836
Inventory: 66507
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Avalanche Energy Rating (Eas) 216 mJ
DS Breakdown Voltage-Min 60V
Pulsed Drain Current-Max (IDM) 42A
Drain-source On Resistance-Max 0.23Ohm
Drain Current-Max (Abs) (ID) 12A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 30nC @ 10V
Current - Continuous Drain (Id) @ 25°C 12A Tc
Input Capacitance (Ciss) (Max) @ Vds 770pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 230m Ω @ 6A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 60W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Subcategory Other Transistors
Additional Feature AVALANCHE RATED
Terminal Finish Tin/Lead (Sn80Pb20)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
