MPF960
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 60V 2A TO-92
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.604011
≥1 USD $2.604011
≥10 USD $2.456619
≥100 USD $2.317568
≥500 USD $2.186382
≥1000 USD $2.062618
Inventory: 1510
Minimum: 1
-
+
Technical Details
Technical
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8541.29.00.95
Subcategory FET General Purpose Power
Voltage - Rated DC 60V
Technology MOSFET (Metal Oxide)
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 2A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code O-PBCY-T3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max 1W Ta
Operating Mode ENHANCEMENT MODE
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 1.7 Ω @ 1A, 10V
Vgs(th) (Max) @ Id 3.5V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds 70pF @ 25V
Current - Continuous Drain (Id) @ 25°C 2A Ta
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Continuous Drain Current (ID) 2A
JEDEC-95 Code TO-226AE
Drain Current-Max (Abs) (ID) 2A
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2004
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Transistor Element Material SILICON
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
