FDMA507PZ
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET P-CH 20V 7.8A 6-Pin MicroFET T/R
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.77
≥100 USD $0.599104
≥500 USD $0.507848
≥1000 USD $0.413688
Inventory: 1163
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-WDFN Exposed Pad
Number of Pins 6
Weight 30mg
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series PowerTrench?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Resistance 24MOhm
Subcategory Other Transistors
Technology MOSFET (Metal Oxide)
Terminal Position DUAL
Number of Elements 1
Power Dissipation-Max 2.4W Ta
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 2.4W
Case Connection DRAIN
Turn On Delay Time 6.4 ns
FET Type P-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 24m Ω @ 7.8A, 5V
Vgs(th) (Max) @ Id 1.5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2015pF @ 10V
Current - Continuous Drain (Id) @ 25°C 7.8A Ta
Gate Charge (Qg) (Max) @ Vgs 42nC @ 5V
Rise Time 14 ns
Drain to Source Voltage (Vdss) 20V
Drive Voltage (Max Rds On,Min Rds On) 1.8V 4.5V
Vgs (Max) ±8V
Fall Time (Typ) 96 ns
Turn-Off Delay Time 192 ns
Continuous Drain Current (ID) 7.8A
Threshold Voltage -500mV
Gate to Source Voltage (Vgs) 8V
Drain to Source Breakdown Voltage -20V
Nominal Vgs -500 mV
Dimensions
Height 750μm
Length 2mm
Width 2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
