FDC021N30
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6 Thin, TSOT-23-6
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
PT8 N 30V/20V, MOSFET
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.41205
≥1 USD $2.41205
≥10 USD $1.97885
≥100 USD $1.9171
≥500 USD $1.85535
≥1000 USD $1.7936
Inventory: 1273
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Feedback Cap-Max (Crss) 30 pF
DS Breakdown Voltage-Min 30V
JEDEC-95 Code MO-193AA
Threshold Voltage 1.8V
Continuous Drain Current (ID) 6.1A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 30V
Gate Charge (Qg) (Max) @ Vgs 10.8nC @ 10V
Current - Continuous Drain (Id) @ 25°C 6.1A Ta
Input Capacitance (Ciss) (Max) @ Vds 710pF @ 15V
Vgs(th) (Max) @ Id 3V @ 250μA
Rds On (Max) @ Id, Vgs 26m Ω @ 6.1A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 700mW Ta
Number of Elements 1
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
HTS Code 8541.29.00.95
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PowerTrench?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 36mg
Number of Pins 6
Package / Case SOT-23-6 Thin, TSOT-23-6
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 13 Weeks
