FCH47N60F
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 600V 47A TO-247
PDF
/
Buying Options
Total Price: USD $9.12
Unit Price: USD $9.12475
≥1 USD $9.12475
≥10 USD $7.48695
≥100 USD $7.25325
≥500 USD $7.0186
≥1000 USD $6.7849
Inventory: 1148
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-247-3
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2004
Series SuperFET?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Reach Compliance Code compliant
Base Part Number FCH47N60
Power Dissipation-Max 417W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 73m Ω @ 23.5A, 10V
Vgs(th) (Max) @ Id 5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 8000pF @ 25V
Current - Continuous Drain (Id) @ 25°C 47A Tc
Gate Charge (Qg) (Max) @ Vgs 270nC @ 10V
Drain to Source Voltage (Vdss) 600V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
