BFL4036
RoHS
/
Package TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 9.6A TO-220FI
PDF
/
Inventory: 6838
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Drain to Source Breakdown Voltage 500V
Gate to Source Voltage (Vgs) 30V
Continuous Drain Current (ID) 9.6A
Turn-Off Delay Time 117 ns
Fall Time (Typ) 46 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 66ns
Gate Charge (Qg) (Max) @ Vgs 38.4nC @ 10V
Current - Continuous Drain (Id) @ 25°C 9.6A Ta
Input Capacitance (Ciss) (Max) @ Vds 1000pF @ 30V
Vgs(th) (Max) @ Id 5V @ 1mA
Rds On (Max) @ Id, Vgs 520m Ω @ 7A, 10V
FET Type N-Channel
Turn On Delay Time 22 ns
Power Dissipation 37W
Element Configuration Single
Power Dissipation-Max 2W Ta 37W Tc
Technology MOSFET (Metal Oxide)
Terminal Finish Tin/Copper/Silver/Nickel (Sn/Cu/Ag/Ni)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2013
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
