APT6021BFLLG
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 600V 29A 3-Pin(3+Tab) TO-247
PDF
/
Inventory: 5990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package TO-247 [B]
Technical
Packaging Tube
Series POWER MOS 7?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 600V
Max Power Dissipation 400W
Technology MOSFET (Metal Oxide)
Current Rating 29A
Number of Elements 1
Power Dissipation 400W
Turn On Delay Time 10 ns
FET Type N-Channel
Rds On (Max) @ Id, Vgs 210mOhm @ 14.5A, 10V
Vgs(th) (Max) @ Id 5V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds 3470pF @ 25V
Current - Continuous Drain (Id) @ 25°C 29A Tc
Gate Charge (Qg) (Max) @ Vgs 80nC @ 10V
Rise Time 7ns
Drain to Source Voltage (Vdss) 600V
Fall Time (Typ) 4 ns
Turn-Off Delay Time 25 ns
Continuous Drain Current (ID) 29A
Gate to Source Voltage (Vgs) 30V
Input Capacitance 3.47nF
Rds On Max 210 mΩ
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
