APT6017LLLG
RoHS
/
Package TO-264-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
PDF
/
Inventory: 3743
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Capacitance - Input 4.5nF
Rds On Max 170 mΩ
FET Technology METAL-OXIDE SEMICONDUCTOR
Gate to Source Voltage (Vgs) 30V
JEDEC-95 Code TO-264AA
Continuous Drain Current (ID) 35A
Turn-Off Delay Time 26 ns
Fall Time (Typ) 6 ns
Polarity/Channel Type N-CHANNEL
Drain to Source Voltage (Vdss) 600V
Rise Time 7ns
Transistor Application SWITCHING
Turn On Delay Time 11 ns
Case Connection DRAIN
Power Dissipation 500W
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 500W
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Current Rating 35A
Terminal Position SINGLE
Voltage - Rated DC 600V
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish TIN SILVER COPPER
Number of Terminations 3
Pbfree Code yes
JESD-609 Code e1
Physical
Package / Case TO-264-3
Mount Through Hole
