IXTT24P20
RoHS
RoHS compliant
RoHS compliantPackage TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET P-CH 200V 24A 3-Pin(2+Tab) TO-268
PDF
/
Buying Options
Total Price: USD $10.03
Unit Price: USD $10.032
≥1 USD $10.032
≥10 USD $8.12152
≥100 USD $7.64368
≥500 USD $6.927087
≥1000 USD $6.353811
Inventory: 262
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Resistance 110MOhm
Terminal Finish PURE TIN
Additional Feature AVALANCHE RATED
Subcategory Other Transistors
Technology MOSFET (Metal Oxide)
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 300W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 300W
Case Connection DRAIN
FET Type P-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 110m Ω @ 500mA, 10V
Vgs(th) (Max) @ Id 5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 4200pF @ 25V
Current - Continuous Drain (Id) @ 25°C 24A Tc
Gate Charge (Qg) (Max) @ Vgs 150nC @ 10V
Rise Time 29 ns
Drain to Source Voltage (Vdss) 200V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 28 ns
Turn-Off Delay Time 68 ns
Continuous Drain Current (ID) 24A
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage -200V
Pulsed Drain Current-Max (IDM) 96A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
